PVA (40-150W) – 40-150W AC-DC On-board Converter
AC-DC On-board Converter series, 19 Models. wide input voltage range. CE certified, CB certified, UL certified, CQC certified, RoHS certified, REACH certified.
Key Features
- 85-900VAC ultra-wide input for coal mining
- 4000-5000VAC high isolation
- Open frame/Enclosed package
- Excellent EMS performance
PVA (40-150W) Model Specifications
| Model | Power | Input | Output | Current | Efficiency | Isolation |
|---|---|---|---|---|---|---|
| PVA40-27B18 | 40W | 85-900 VAC | 18 VDC | 2.222A | 85% | 4000VAC |
| PVA40-27B24 | 40W | 85-900 VAC | 24 VDC | 1.667A | 85% | 4000VAC |
| PVA40-27B30 | 40W | 85-900 VAC | 30 VDC | 1.333A | 85% | 4000VAC |
| PVA40-26B12 | 40W | 460-1500 VAC | 12 VDC | 3.4A | 85% | 4200VAC |
| PVA40-26B28 | 40W | 460-1500 VAC | 28 VDC | 1.43A | 85% | 4200VAC |
| PVA40-26B35 | 40W | 460-1500 VAC | 35 VDC | 1.15A | 85% | 4200VAC |
| PVA70-27B28-C | 70W | 85-900 VAC | 28.5 VDC | 2.46A | 85% | 4000VAC |
| PVA70-27B24R2 | 70W | 85-900 VAC | 24 VDC | 2.917A | 85% | 4000VAC |
| PVA70-27B28R2 | 70W | 85-900 VAC | 28 VDC | 2.5A | 85% | 4000VAC |
| PVA70-27B35R2 | 70W | 85-900 VAC | 35 VDC | 2A | 85% | 4000VAC |
| PVA120-27B24R2 | 120W | 85-900 VAC | 24 VDC | 5A | 85% | 4000VAC |
| PVA120-27B28R2 | 120W | 85-900 VAC | 28 VDC | 4.286A | 85% | 4000VAC |
| PVA120-27B35R2 | 120W | 85-900 VAC | 35 VDC | 3.428A | 85% | 4000VAC |
| PVA120-26B24R2 | 120W | 85-1300 VAC | 24 VDC | 5A | 85% | 5000VAC |
| PVA120-26B28R2 | 120W | 85-1300 VAC | 28 VDC | 4.29A | 85% | 5000VAC |
| PVA120-26B35R2 | 120W | 85-1300 VAC | 35 VDC | 3.43A | 85% | 5000VAC |
| PVA200-26B24R2 | 200W | 85-1300 VAC | 24 VDC | 8.33A | 85% | 5000VAC |
| PVA200-26B28R2 | 200W | 85-1300 VAC | 28 VDC | 7.14A | 85% | 5000VAC |
| PVA200-26B35R2 | 200W | 85-1300 VAC | 35 VDC | 5.71A | 85% | 5000VAC |
Applications
- Embedded systems and IoT devices
- Smart home and building controllers
- Metering and monitoring equipment
- Low-power standby power supplies
Product Overview
The PVA (40-150W) is a professional-grade ac-dc on-board converter designed for demanding industrial environments. With a power range of 40-150W, this series offers 19 models with various output voltages to meet diverse application requirements. Key advantages include wide input voltage range, making it suitable for industrial automation, control systems, and embedded applications. All models are ce certified, cb certified, ul certified, cqc certified, rohs certified, reach certified certified, ensuring compliance with international safety and EMC standards. ModulesLink manufactures each unit under strict quality control with 100% load testing and burn-in procedures.
Technical Details
The PVA series features ac-dc on-board converter architecture with input range of 85-900 VAC / 460-1500 VAC / 85-1300 VAC, providing output options of 18 VDC, 24 VDC, 30 VDC, 12 VDC, 28 VDC, 35 VDC, 28.5 VDC at up to 85% efficiency. The robust design incorporates comprehensive protection circuits including overcurrent protection (OCP), overvoltage protection (OVP), overtemperature protection (OTP), and short-circuit protection. The high isolation voltage ensures safe operation in noisy industrial environments, while the wide operating temperature range guarantees reliable performance in harsh conditions. Each model undergoes 100% electrical testing and aging tests before shipment.
Quality & Reliability
ModulesLink implements a rigorous quality management system certified to ISO 9001 standards. The PVA series carries CE certified, CB certified, UL certified, CQC certified, RoHS certified, REACH certified certifications, demonstrating compliance with IEC/EN/UL safety standards and RoHS/REACH environmental regulations. Every power supply is subjected to 100% load testing, hi-pot testing, and thermal cycling before leaving the factory. The mean time between failures (MTBF) exceeds 500,000 hours under nominal conditions at 25°C ambient temperature. ModulesLink offers a 3-year warranty on all industrial-grade power supplies, reflecting confidence in product reliability.
Ordering Information
To order PVA (40-150W) models, select the appropriate output voltage and power rating from the model list above. Each model number follows a standardized naming convention indicating output parameters. For OEM/ODM inquiries, custom output voltages, modified mechanical dimensions, or special input ranges can be accommodated with minimum order quantities (MOQ). Contact ModulesLink sales team through the Request Quote button for pricing, lead time, and technical support. Samples are available for qualified customers to evaluate before volume orders.
