Communication Transceiver Module
RS-232 Transceiver – 0.3W Communication Transceiver Module
Communication Transceiver Module series with 11 models. wide operating temperature. CE certified, CB certified, UL certified, CQC certified, RoHS certified, REACH certified.
Key Features
- Isolated RS-232 transceiver module
- Up to 5000VDC isolation voltage
- ESD protection up to ±8kV
- Surge protection up to ±4kV
- Operating temperature -40°C to +85°C
- Supports up to 250kbps data rate
RS-232 Transceiver Model Specifications
| Model | Power | Input | Output | Current | Efficiency | Isolation |
|---|---|---|---|---|---|---|
| TD331S232H | √W | 1 VAC / 115.2K VDC | 3.3 VDC | 2500VDC | SMD% | High rate |
| TD531S232H | √W | 1 VAC / 115.2K VDC | 5 VDC | 2500VDC | SMD% | High rate |
| TD301D232H | √W | 1 VAC / 115.2K VDC | 3.15-3.45 VDC | 3000VDC | DIP% | High rate |
| TD501D232H | √W | 1 VAC / 115.2K VDC | 4.75-5.25 VDC | 3000VDC | DIP% | High rate |
| TD301D232HG | √W | 1 VAC / 115.2K VDC | 3.15-3.45 VDC | 3000VDC | DIP% | High rate |
| TD501D232HG | √W | 1 VAC / 115.2K VDC | 4.75-5.25 VDC | 3000VDC | DIP% | High rate |
| TD302D232H | √W | 2 VAC / 115.2K VDC | 3.3 VDC | 2500VDC | DIP% | High rate |
| TD502D232H | √W | 2 VAC / 115.2K VDC | 5 VDC | 2500VDC | DIP% | High rate |
| TD541S232H | √W | 1 VAC / 120K VDC | 5 VDC | 5000VDC | DFN% | Ultra-small, ultra-thin, chip-le |
| TD041S232H | 0.3W | 1 VAC / 120K VDC | 3.3,5 VDC | 3750VDC | DFN% | Ultra-small, ultra-thin, chip-le |
| TD341S232H | √W | 1 VAC / 120k VDC | 3.3 VDC | 5000VDC | DFN% | Ultra-small, ultra-thin, chip-le |
Applications
- Industrial communication networks (CAN, RS-485, RS-232)
- Building automation protocols
- Process control and SCADA systems
- Isolated data transmission
